Strap guiding arch size
L. mm. 800 – 1200 – 1600 – 2000
H. mm. 800 – 1200 – 1600 – 2000 – 2400
Strap feed head
Feeding and recovery with automatic cycle
Strap
Normal or high resistance steel
Strap dimensions
Width from mm. 12 to mm. 19
On request from mm. 25 to mm. 32
Thickness from mm. 0,50 to mm. 1
Strap dispenser
Inside diameter mm. 400 (adjustable from mm. 395 to 405)
Bayonet unit
On request
Mobile machine
On request
Hand tool
On request
Electric connection
400v – 50hz – 3Ph
Pneumatic connection
6 bar (only for hand tool)
Technical details
Available versions
Electrical box
Complete with PLC
Options
90° turn table to carry out cross strapping
Standard strap guiding arch size
| Wmm \ Hmm | 800 | 1200 | 1600 | 2000 | 2400 |
| 800 | • | • | • | • | • |
| 1200 | • | • | • | • | • |
| 1600 | • | • | • | • | • |
| 2000 | • | • | • | • | • |
| 2400 | • | • | • | • | • |
Working cycle
When the pack to strap is in the correct position, the operator pushes a button and the strap is automatically feeded around the pack; finished to strap with the strapping hand tool (option) the operator, by another push button, gives to the machine the start signal to recovery automatically the excess of the strap and to feed the strap in the strap guiding arch for the next cycle.
